Korg D8 800元
八轨综合录混话放 吉他D.I 两话筒 SCSI , S/PDIF 数码接口 鼓机 预设效果音色链
http://2.taobao.com/item.htm?id= ... .1000925.0.0.2rbli7
SPECIFICATIONS
Number of Tracks: 8
Simultaneous Recording: 2 tracks
Recording Time: 34 minutes of 8-track recording (time dynamically allocated) using internal 1.4Gb drive
External Drives: up to seven external drives may be fitted, with a capacity of up to 4Gb.
MIDI Sync: MTC and MIDI Clock transmitted, MMC received
Mixer: Digital, 12 channels, with stereo mix buss plus two aux busses, one feeding the internal effects processor
Automation: 20 Scenes (snapshots) per song
Effects: 24-bit, 44.1kHz with 65 presets, 65 user memories, 50 effects types and 38 effects chains
Frequency Response: 10kHz-21kHz, +/- 1dB
S/N Ratio: 92dB or better @ IHF-A
THD: Less than 0.03% (20Hz to 20kHz)
Converters: 18-bit/44.1kHz
EFFECTS
Internal effects come from an on-board processor based on Korg's Pandora chip, providing 64 multi-effect presets, plus room to store 64 more of your own edits. In addition to the usual effects, there are also dynamics and EQ treatments, as well as guitar amp and speaker simulators. The D8's analogue inputs have a switchable high-impedance guitar mode, so you don't even need to use a DI box when recording guitar.
In total there are 50 effects types, and an effects patch can comprise a chain of up to four effects. There are 11 categories of preset:
* Reverb/Delay
* Modulation
* Dynamics
* Equaliser
* Electric Guitar
* Acoustic Guitar
* Electric Bass
* Vocal
* Drums
* Keyboard
* Special
Some effects are mono in/stereo out, while others are stereo in and out, which is useful when processing stereo mixes. When effects are recorded to single tracks along with the instrument, they will, of course, be mono
KORG D8 £849
pros
Good sounding 16-bit, 44.1kHz recording system without data compression.
Clear, compact layout.
Easy to use.
Integral guitar DI and assortment of guitar-related effects, as well as the more usual studio effects.
Inbuilt drum patterns and comprehensive tempo map facilities.
Integral SCSI interface, S/PDIF digital I/O and the ability to back up onto DAT or an external SCSI device.
Snapshot mix automation.
规范
跟踪数量:8
同时记录:2
记录时间:34分钟8-track记录(时间动态分配的)使用内部1.4 gb硬盘
外部驱动器:7外部驱动器可以安装,4 gb的容量。
MIDI同步:MTC和MIDI时钟传输,MMC
搅拌机:数字12频道,与立体混合巴斯加两个辅助公交车,一个喂处理器内部的影响
自动化:20场景(快照)每首歌曲
效果:24位,65年44.1 khz,预设,65个用户记忆,50个连锁效应类型和38效应
频率响应:10 khz-21khz + / - 1 db
信噪比:92分贝或@ IHF-A更好
官:不到0.03%(20赫兹到20 khz)
转换器:18位/ 44.1 khz
影响
内部影响来自机载处理器基于Korg的潘多拉芯片,提供64多级预设,加上房间存储64多自己的编辑。除了通常的效果,也有动力和EQ治疗,以及吉他放大器和扬声器模拟器。D8的模拟输入高阻抗吉他模式切换,所以你甚至不需要使用DI框当录制吉他。
总共有50影响类型,影响补丁可以组成一个四链的影响。有11个类别的预设:
*混响/延迟
*调制
*动态
*扳平比分
*电吉他
*原声吉他
*电子贝斯
*声音
*鼓
*键盘
*特殊
一些影响是单声道/立体声,而另一些则立体,这是有用的在处理立体混合。当影响记录单跟踪仪器,他们会,当然,mono
KORG D8£849
优点
好声音16位,44.1 khz记录系统没有数据压缩。
清晰,紧凑的布局。
易于使用。
积分吉他DI和各式各样的guitar-related效果,以及更常见的工作室的效果。
内置的鼓模式和节奏地图综合设施。
积分SCSI接口,S / PDIF数字I / O和备份的能力到DAT或外部SCSI设备。
快照混合自动化。
|
|
，
